SC-ML736E Ultrasonic stencil cleaner

Simple to use

Convenient touch panel display
Comfortable one-button operation
Automatic process from cleaning todrying

Economical

Lowoperating costs –
Lowelectrical consumption –
Lowmaintenance

Compact type

Perfectsolution for dead-space of your factor

SC-ML736E’sFeatures

·       Easy Operation Touch Panel.Automatic operation fromcleaning to drying! Real-time display on touch panel.

·       Open door with one hand

·       Large reduction of solvent consumption by 30% scale-downof cleaning space.

·       Can be cleaned by solvent only 18 liters.

·       State of the machine is visible by level gate for solventand large observation window.

·       Replacement of the solvent and maintenance is easy bydrawer type door.

·       Simple and easy Ergonomics Design

Stencil size(mm)


550×600
550×650
736×736
(mm)
*Adapter required.

Specifications

Product modelSC-ML736ES
Overall dimension ・ weightW: 1,290 x D:    553 x H: 1,466 mm
   Approx. 137kg
Power supply ・ Power consumptionAC 100 V 50/60    Hz
   350 VA
ultrasonic40 kHz, 150 W
Corresponding steel plate sizeL: 550 x W:    600 mm *1
   L: 550 x W: 650 mm   *1
   L: 736 x W: 736 mm
Air supply0.4 MPa, 800    NL/min
Exhaust air5 m/sec、Diameter φ98
time清洗 Approx. 3 min *2
   干燥 Approx 5 min *2
